The Lewisville, Texas facility is situated on 7.5 acres with 100,000 sft of covered warehouse to serve your toll processing needs. Located a short 1.5 miles from I-35E, our yard can accommodate tractor-trailer traffic with ease. Rail service is accomplished through a short-line carrier who catches rail cars from Union Pacific (UP).

Lewisville, TX
202 S. Railroad St.
Lewisville, TX 75057
Toll Free: 888.686.5815
Tel: 972.436.2505
Fax: 972.436.2056

iso 9001 ANAB accredited

Specifications:

Slitting

Materials Aluminum
Stainless Steel
Carbon Steel 		Galvanized Steel
Pre-Painted
Coil O.D. 72” maximum (Entry & Exit)
Coil I.D. 20” min (Entry)
20” – 24” (Exit)
Incoming Width 15” minimum 62” maximum
Slitting Width .625” minimum 60” maximum
Material Thickness 0.015” minimum 0.187” maximum
Weight Capacity 60,000# maximum (handling only)
45,000# maximum (slitting)

Cut-To-Length Line

Our Cut-To-Length line can level sheets ranging from 0.135″ thickness down to .035″. The maximum width for master coils is 60″ and the minimum width is 18″. The uncoiler can support weights up to 30,000#. The minimum length we can level is 30″ and the maximum length is 144″.

    Incoming Capacity

  • 30,000# Master Coils – All carbon, Aluminum, Stainless & PTD
  • 60.00″ Maximum Coil Width (+ 1 ½”) / 18.00″ Minimum Coil Width, 76″ Max OD / 16″
    Minimum ID & 24″ Maximum ID

    •

    Leveling Capabilities

  • .056-.187 x 60″ Wide Straightener
  • .016-.100 Herr Voss Corrective Leveler

    •

    Production Capacity

  • .016-.156 Gauge
  • +/-.005 Width Tolerance (If slit prior / otherwise mill edge)
  • +.015 /-.015 Length Tolerance
  • 144″ Maximum Length / 30″ Minimum Length

    •

    Packaging Capacity

  • 20,000# Maximum Stack weight / 24″ Maximum Stack Ht. (Including Pallet)
